Component
Rear combination light bulb replacement (5 Door)
(1) Tail light
(2) Rear turn signal light
(3) Back-up light
(4) Stop and tail light
(5) Side marker
1. Open the tailgate.
2. Loosen the light assembly retaining screws with a cross-tip screw ...
Special Service Tools
Special Service Tools
Tool
(Number and name)
Illustration
Use
09200-38001,3N000 (Beam)
09200-2S100 (Adapter)
09200-2S200 (Supporter)
...
ESC Control Module. Components and Components Location
Components
1. Front - left tube
2. Rear - right tube
3. Rear - left tube
4. Front - right tube
5. MC2
6. MC1
7. ABS control module (HECU)
8. Damper
...
