Input Speed Sensor. Troubleshooting
Signal Waveform
Fig 1) Input/Output speed sensor at low speed
Fig 2) Input/Output speed sensor at high speed
...
Removal
Wiper and Washer Switch
1.
Disconnect the negative (-) battery terminal.
2.
Remove the steering column upper (A) and lower (B) shrouds aft ...
Replacement
Rear Brake Pads
1.
Loosen the guide rod bolt (B) and then remove the rear caliper
body (A).
Tightening torque:
21.6 ~ 31 ...
